2026 Horizon HZH 30K 96 in GN Telescopic 16 ft / 2 ft

The HZH 30K 96" Telescopic Dump Trailer combines unmatched durability and versatility. With a 30,000 lbs GVWR, 12" I-beam frame, Telescopic Dump system, and advanced safety features, it's engineered for heavy-duty performance. Available in multiple lengths, side heights, and custom color options, it ensures reliability and style for any demanding job.

BUILT TO ENDURE, DESIGNED TO PERFORM

UNLEASH HEAVY-DUTY POWER

The HZH 30K 96" Telescopic Dump Trailer redefines durability. Featuring a 12" I-beam frame, telescopic lift system, and 16k dual-axle suspension, it handles up to 30,000 lbs GVWR with ease. Choose from vibrant custom colors and configurations like adjustable side heights and bed lengths. When reliability is non-negotiable, this trailer delivers.

EFFICIENCY WITH EVERY LOAD

OPTIMIZE YOUR WORKFLOW

The HZH 30K dump trailer offers power and precision. Its Telescopic Dump cylinder ensures smooth lifting at angles up to 48°, while 8' heavy-duty ramps simplify loading. A spacious lockable toolbox and manual tarp system enhance utility. Whether hauling debris or equipment, it's the ultimate workhorse you can rely on.

TOUGHNESS MEETS STYLE

MAKE A STATEMENT

Stand out with the HZH 30K trailer's vibrant two-tone color options, military-grade powder coat finish, and bold design. Engineered for performance, its heavy-duty steel construction is complemented by practical features like extra visibility marker lights, welded D-rings, and safety-grade components. It's not just a trailer—it's a statement of excellence.

Features May Include:

Standard Features

Highlights

• 12" I-Beam (19 Lbs/Ft)
• Slide In Side Step On Both Sides
• Lockable Toolbox (Houses Batteries And Pump)
• Ramp Pockets W/ 8' Long Heavy Duty Slide In 4" Channel Ramps
• Extra Marker Lights For Added Visibility
• 4 D-Rings Welded Inside Box
• Manual Tarp Kit
• Telescopic Dump
• Weld On Spare Tire Mount
• Neckboss 12" Engineered I-Beam
• Mega Lockable Toolbox

Trailer Specs

Dimensions

• Available Lengths: 16', 18', 20'
• Side Height: 2'
• Bed Width: 96"
• Bed Height: 37"

Weight Rating

• GAWR: 16,000 Lbs
• GVWR: 30,000 Lbs

Finish

• Paint Type: Powdercoat
• Prep: Steel Grit Blasted

Colors

• Military Green
• Desert Tan
• Flame Orange
• Midnight Black
• Spectra Yellow
• Blue Horizon
• Lime Green
• Ash Grey
• True Red
• Pearl White
• Cloud Grey
• Navy Blue
• Style: 2 Tone Colors Available, Chassis / Dump

Warranty

• Axle Warranty: 5 Year Spring Axle Warranty
• Trailer Warranty: 3 Year Frame / 1 Year Parts Warranty

Tongue

Tongue

• Type: Neckboss 12" Engineered I-Beam
• Length: 98" (From Behind Riser)
• Height: 70" High (From Underneath Neck)
• Spare: Weld On Spare Tire Mount

Coupler

• Standard Coupler: Adjustable 2-5/16" Gn Coupler (30,000 Lbs)

Jacks

• Front Jack: 2 Side Wind Spring Loaded Drop Jack Legs (12,000 Lbs)

Toolbox

• Toolbox: Mega Lockable Toolbox

Safety System

• Safety Chains: 3/8" Grade 70 Safety Chain W/Clevis Hook (2 Each)

Chassis

Frame

• Main Frame: 12" I-Beam (22 Lbs/Ft)
• Steps: Side Step On Both Sides
• Torque Tube20' Only: 4,1/2" Tube

Dump

Bed

• Bed Width: 96"
• Bed Height: 37"
• Flooring: 7Ga. Steel Bed
• Frame: 3" X 4" X 11Ga. Tubing Bed Frame
• Crossmembers: 3" Channel (3.50 Lbs/Ft) 16" Spacing
• D-Rings: 4 D-Rings Welded Inside Box
• Dump Angle: 44° - 48°

Rear

• Gate: 3 Way Door - Spreader Gate
• Ramps: Ramp Pockets W/ 8' Long Heavy Duty Slide In 4" Channel Ramps (5,000 Lbs Wheel Rating Each Only Over Area Of 12" Or More)

Sides

• Height: 2'
• Top Rail Width: 96"
• Thickness: 10Ga.
• Type: Rounded Steel
• Top Rail: 3" X 5" X 11Ga. Tubing
• Stake Pockets: 1,5/8" X 3,5/8" (Id) Stake Pockets
• Hooks: 3/8" Round "J" Hooks
• Tarp: Ground Level Crank Over Tarp Kit

Lift System

Hydraulics

• System: 2 Button Hydraulic - Power Up / Gravity Down
• Pump: KTI 12V Hydraulic Pump
• Controller: 14' Control Cable

Dump Lift

• Lift Cylinder: Telescopic Cylinder

Running Gear

Tires

• Type: Radial Tires
• Size: ST235/75R17.5, Dual
• Ply: 18
• Rating: 5,675 Lbs
• Rims: 17.5" Black Mod Wheels

Suspension

• Axle Type: 16K Electric Brake Auto Adjust Dual Oil Bath Spring Axles
• Bolt Pattern: 8 On 10.83"
• Axle Count: 2
• Suspension Type: Heavy Duty Double Slipper Mechanical Suspension
• Axle Warranty: 5 Year Spring Axle Warranty

Electrical And Lighting

Battery And Charging

• Battery: 2 - Interstate 27 Deep Cycle Batteries
• Solar: 10 Watt Solar Panel
• Charging System: 110V Integrated Trickle Charger
• Wiring Harness: All-Weather Wiring Harness (7-Way Rv)
• Frame Wiring: Double Insulated Wiring Harness

Lighting

• Lights: Dot Approved Tecniq Led Lights

Safety

• Reflective Tape: 3M Dot Compliant Reflective Tape

Options

Base Model

• HZH2GN162T-30Khzh Gn 16' X 96" X 2' 30K Tandem Axle Telescopic Dump Trailer
• HZH2GN182T-30Khzh Gn 18' X 96" X 2' 30K Tandem Axle Telescopic Dump Trailer
• HZH2GN202T-30Khzh Gn 20' X 96" X 2' 30K Tandem Axle Telescopic Dump Trailer

Tongue

• HZH-10412K Ram 2 Speed Jacks $273.00 (Usd)
• HZH-10612K Hydraulic Jacks $1,982.50 (Usd)
• HZH-3026" GN Riser Increase $149.50 (Usd)
• HZH-301Deck On The Neck (Flip Down Spare Tire Mount Included) $2,457.00 (Usd)
• 508-0052 - D-Rings Welded Across Deck On The Neck (1/2" - 4,000 Lbs) $41.60 (Usd)
• 508-0064 - D-Rings Welded Across Deck On The Neck (1/2" - 4,000 Lbs) $84.50 (Usd)
• 503-007Shocker Hitch 2,5/16" Gn Coupler (30,000 Lbs) $1,638.00 (Usd)

Chassis

• HZH-2031 - Side Mount Undercarriage Toolbox (44"L X 17"W X 14"H) $481.00 (Usd)
• HZH-624Engineered Beam /Neck (High-Tensile Steel)

Dump

• HZH-5193' High Sides $54.60 (Usd) Per Linear Ft
• HZH-5204' High Sides $104.00 (Usd) Per Linear Ft
• HZH-40212" Crossmember Spacing $15.60 (Usd) Per Linear Ft
• HZH-707Electric Tarp Kit 16' Dump  $1,228.50 (Usd)
• HZH-704Electric Tarp Kit 18', 20' Dump  $1,638.00 (Usd)

Lift System

• 509-019Tuff Wireless 2 Button Remote (Telescopic) $708.50 (Usd)
• 509-014Tuff Wireless 4 Button Remote (Telescopic - Hydraulic Jacks) $858.00 (Usd)
• 509-006Tuff Wireless 4 Button Remote (Hydraulic System And Tarp)-
• 509-028Tuff Wireless 4 Button Remote (Telescopic - Tarp) $858.00 (Usd)
• 509-027Tuff Wireless 8 Button Remote (Telescopic - Hydraulic Jacks - Tarp)  $1,254.50 (Usd)

Running Gear

Spare Tire Options

• 501-114St235/75R17.5 18 Ply Tire (5,675 Lbs) $409.50 (Usd)

Finish

• HZH-8032 - Tone Colors Chassis / Dump Box $325.00 (Usd)
• HZH-80514Ft Zinc Primer Undercoat $682.50 (Usd)
• HZH-80716Ft-18Ft Zinc Primer Undercoat $1,027.00 (Usd)
• HZH-81520Ft & Up Zinc Primer Undercoat $1,365.00 (Usd)
• HZH-821Side Mount Undercarriage Toolboxes Painted Black $273.00 (Usd) Per Toolbox
