2026 Horizon HHZ 40K 102 in GN HOTSHOT 40 ft

The HHZ 40K 102" Hotshot Flatdeck Gooseneck Trailer offers unmatched durability and performance. Featuring a 40,000 lbs GVWR, dual 16k axles, and a bridged 14" I-beam frame, this trailer is built for heavy-duty tasks. With lengths from 30' to 44', choose the size that fits your hauling needs.

Your Heavy-Duty Partner on the Road
BUILT TO HAUL IT ALL

The HHZ 40K 102" Hotshot Flatdeck Gooseneck Trailer is designed for serious hauling. With a robust GVWR of 40,000 lbs and lengths ranging from 30' to 44', it meets every demand. Equipped with dual 16k axles, a durable pine lumber floor, and Tecniq LED lights, this trailer ensures reliability. Upgrade today!

Heavy-Duty Features Tailored for You
MAXIMUM PERFORMANCE, MINIMUM EFFORT

This trailer boasts a bridged 14" I-beam frame and a straight deck for stability. The Neckboss engineered I-beam ensures strength, while ramp pockets with heavy-duty ramps make loading easy. Add customizable options like hydraulic jacks or Blackwood flooring to make it your own. Discover the ultimate in flatdeck performance now!

Quality Backed by Warranties
RELIABILITY THAT LASTS

The HHZ 40K is steel grit blasted and powder-coated for a long-lasting finish. Choose from vibrant colors like Military Green or Midnight Black. Enjoy peace of mind with a 6-year axle warranty and a 3-year frame warranty. Elevate your hauling experience with a trailer that works as hard as you do!

Features may include:

Highlights

• Bridged 14" I-Beam (22 lbs/ft)
• Neckboss 14" Engineered I-Beam
• Diamond Mesh Wire Floor Storage
• Weld On Spare Tire Mount
• 2" X 6" X 7ga. TUBING BED FRAME
• Straight Deck
• Ramp Pockets w/ 8' Long Heavy Duty Slide In 4" Channel Ramps
• SLIDE IN SIDE STEP ON BOTH SIDES
• 2 Speed Jost Side Wind Spring Loaded Drop Jack Legs (17,500 lbs)
• Hutchens Suspension

Options:

Base Model

• HHZ2GN30102-40KHHZ GN 30' x 102" 40K Tandem Axle Hotshot Flatdeck Trailer
• HHZ2GN32102-40KHHZ GN 32' x 102" 40K Tandem Axle Hotshot Flatdeck Trailer
• HHZ2GN34102-40KHHZ GN 34' x 102" 40K Tandem Axle Hotshot Flatdeck Trailer
• HHZ2GN36102-40KHHZ GN 36' x 102" 40K Tandem Axle Hotshot Flatdeck Trailer
• HHZ2GN38102-40KHHZ GN 38' x 102" 40K Tandem Axle Hotshot Flatdeck Trailer
• HHZ2GN40102-40KHHZ GN 40' x 102" 40K Tandem Axle Hotshot Flatdeck Trailer
• HHZ2GN42102-40KHHZ GN 42' x 102" 40K Tandem Axle Hotshot Flatdeck Trailer
• HHZ2GN44102-40KHHZ GN 44' x 102" 40K Tandem Axle Hotshot Flatdeck Trailer

Tongue

• HHZ-11320K Hydraulic Jacks$3,003.00 (USD)
• HHZ-201Locker Style Toolbox$1,449.50 (USD)
• HHZ-3026" Gn Riser Increase$149.50 (USD)
• HHZ-301Deck on the Neck (96"L X 102"W) *Flip Down Spare Tire Mount Included*$2,457.00 (USD)
• 508-0052 - D-Rings Welded Across Deck On The Neck (1/2" - 4,000 lbs)$41.60 (USD)
• 508-0064 - D-Rings Welded Across Deck On The Neck (1/2" - 4,000 lbs)$84.50 (USD)
• 503-008Shocker Hitch 3" Gn Coupler (40,000 lbs)$2,184.00 (USD)

Chassis

• HHZ-20320' - 44' Deck 1 - Side Mount Undercarriage Toolbox (44"L x 17"W x 14"H)$481.00 (USD)
• HHZ-21420' - 44' Deck 2 - Side Mount Undercarriage Toolboxes (44"L x 17"W x 14"H)$955.50 (USD)
• HHZ-21530' - 44' Deck 3 - Side Mount Undercarriage Toolboxes (44"L x 17"W x 14"H)$1,436.50 (USD)
• HHZ-21630' - 44' Deck 4 - Side Mount Undercarriage Toolboxes (44"L x 17"W x 14"H)$1,911.00 (USD)
• HHZ-2041 - Side Mount Undercarriage Dunnage Rack (44"L x 22"W x 14"H)$481.00 (USD)
• HHZ-2181 - Side Mount Undercarriage Dunnage Rack (9'L x 22"W x 14"H)$481.00 (USD)

Deck

• HHZ-4105' Dovetail With 2 Mountain Ramps$1,436.50 (USD)
• HHZ-4303' Dove Tail Lumber Floor w/ 24" x 5' Heavy Duty 4" Channel Stand Up - Fold Down Ramps w/ 10ga. Mesh Covering (6,000 LBS WHEEL RATING EACH ONLY OVER AREA OF 12" OR MORE)$1,365.00 (USD)
• HHZ-40212" Crossmember Spacing$15.60 (USD) per linear ft
• 506-004Deck Sides Blackwood "Classic" Rubber Infused Lumber$19.50 (USD) per linear ft
• 506-005Full Deck Blackwood "Classic" Rubber Infused Lumber$37.70 (USD) per linear ft
• HHZ-411Ratchet Slide Track Left Side$20.80 (USD) per linear ft
• HHZ-412Ratchet Slide Track Right Side$20.80 (USD) per linear ft
• 507-0076 - 4" Sliding Ratchets$572.00 (USD)
• 507-0088 - 4" Sliding Ratchets$767.00 (USD)
• 507-00910 - 4" Sliding Ratchets$955.50 (USD)
• 507-01012 - 4" Sliding Ratchets$1,144.00 (USD)
• 507-0116 - Weld On 4" Ratchets Right Side$572.00 (USD)
• 507-0128 - Weld On 4" Ratchets Right Side$767.00 (USD)
• 507-01310 - Weld On 4" Ratchets Right Side$955.50 (USD)
• 507-01412 - Weld On 4" Ratchets Right Side$1,144.00 (USD)
• 507-0044" x 30' Kinedyne Winch Strap with Flat Hook (5,400 lbs)$54.60 (USD) each
• 508-0014 Additional D-Rings Welded Across Deck (1/2" - 4,000 lbs)$84.50 (USD)
• 508-0026 Additional D-Rings Welded Across Deck (1/2" - 4,000 lbs)$123.50 (USD)
• 508-0038 Additional D-Rings Welded Across Deck (1/2" - 4,000 lbs)$162.50 (USD)

Lift System

• 509-016Tuff Wireless 2 Button Remote (Hydraulic Jacks)$708.50 (USD)
• 509-018Tuff Wireless 4 Button Remote (Hydraulic Jacks - Winch)$858.00 (USD)
• 504-01417.5k Steel Cable Winchmax Winch$2,255.50 (USD)
• 504-01517.5k Synthetic Rope Winchmax Winch$2,938.00 (USD)
• 504-01620k Steel Cable Winchmax Winch$2,834.00 (USD)
• 504-01720k Synthetic Rope Winchmax Winch$3,445.00 (USD)

Running Gear

• Brakes upgrade option
  • 501-2072 - 16k Elec / Hydraulic Disc Brake Dual Oil Bath Axles w/ Hydrastar CAM$5,187.00 (USD)
• Ridewell air ride suspension upgrade/ axles options
  • 500-210Standard Axles w/ Air Ride Suspension$9,964.50 (USD)
  • 500-2182 - 16k Elec / Hydraulic Disc Brake Dual Oil Bath Axles w/ Hydrastar CAM w/ Air Ride Suspension$15,151.50 (USD)
• Lift axle ridewell air ride upgrade/ axles options
  • 500-211Standard Axles w/ Air Ride Suspension w/ 1 Lift Axle$10,920.00 (USD)
  • 500-2202 - 16k Elec / Hydraulic Disc Brake Dual Oil Bath Axles w/ Hydrastar CAM w/ Air Ride Suspension w/ 1 Lift Axle$16,107.00 (USD)

Electrical and Lighting

• 505-00110 Watt Solar Panel$481.00 (USD)
• HHZ-3052 - Cargo Lights Mounted On Riser$546.00 (USD)

Finish

• HHZ-81520ft & Up Zinc Primer Undercoat$1,365.00 (USD)
• HHZ-817Ramps Painted Black$409.50 (USD)
• HHZ-821Side Mount Undercarriage Toolboxes Painted Black$273.00 (USD) per toolbox
• HHZ-823Side Mount Undercarriage Dunnage Racks Painted Black$344.50 (USD) per rack
